Technical specifications
| Parameters | Measuring units |
Accuracy |
Measuring range | Resolution |
| Infrared temperature | °C / °F | ±(2% of value +2°C) ±(-2% of value +4.3°F) from -40 to 32°F ±(2% of value +3°F) from 32 to 932°F |
from -40 to +500°C from -40 to 932°F |
0.1°C 0.1°F |
| Ambient temperature** | °C / °F | – | from 0 to 50°C from 32 to 122°F |
0.1°C 0.1°F |
*All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions.
**Only available on the app
