Chauvin Arnoux : F405 1000V AC/DC TRMS Digital Multimeter
To deal with the highest level of low-voltage electrical installations, the F400 Series has a high protection rating and is ideal for maintenance, testing, monitoring and diagnostics on medium-power installations.
Download PDF
RM4,260.00
To deal with the highest level of low-voltage electrical installations, the F400 Series has a high protection rating and is ideal for maintenance, testing, monitoring and diagnostics on medium-power installations.
Download PDF
Availability : In Stock
Equipped with a fast 12-bit TRMS digital acquisition system, F405 clamps offer particularly accurate measurements whatever the signal’s waveform.
Be the first to review “Chauvin Arnoux : F405 1000V AC/DC TRMS Digital Multimeter”
| Specifications: | Clamping diameter: 48 mm |
| Current: 1,000 A AC / 1,500 A DC | |
| AC and DC voltage up to 1000 V | |
| Resistance and audible continuity | |
| Power values (W, var, VA, PF) and harmonics (THDf, THDr) | |
| "2-wire method" phase rotation | |
| Automatic AC/DC detection | |
| TrueInrush current measurement | |
| Min, MAX, Peak+, Peak- | |
| ReLative (ΔX) and differential (ΔX/X) measurements | |
| CAT IV 1,000 V | |
| IP54 protection rating |
